Product Description

The Access panel consists of an aluminum frame which virtually disappears once installed in the wall. Equipped with concealed mechanical touch-latches, the round access door is available with either 1/2″ (12.7 mm) or 5/8″ (15.9 mm) drywall and blends seamlessly into the surrounding wall or ceiling and just a small reveal of 1/16” (1.59 mm) is visible between the outer frame and door hatch. The door is fully removable and offers a very functional yet aesthetically pleasing solution.

Access Panel Design

Removable
Ready-To-Paint Access Door

Fire protection

Non-Rated

Usage

Ceiling & Walls

Model

System R

Looking for measurements to plan for your project? See below for what you need.
r-measurment

Standard Dimensions with ½” & ⅝” Drywall Inlay

System R
A(in)
A(mm)
B(in)
B(mm)
C(in)
C(mm)
D(in)
D(mm)
R200G127
Ø 7.87
Ø 200
Ø 7.72
Ø 196
Ø 10.24
Ø 260
Ø 8.32
Ø 204
R300G127
Ø 11.81
Ø 300
Ø 11.65
Ø 296
Ø 14.17
Ø 360
Ø 11.97
Ø 304
R400G127
Ø 15.75
Ø 400
Ø 15.59
Ø 396
Ø 18.11
Ø 460
Ø 15.91
Ø 404
R500G127
Ø 19.69
Ø 500
Ø 19.53
Ø 496
Ø 22.05
Ø 560
Ø 19.84
Ø 504
R600G127
Ø 23.62
Ø 600
Ø 23.46
Ø 596
Ø 25.98
Ø 660
Ø 23.78
Ø 604

Need additional help? Below you will find installation instructions and installation videos

Product Information:
Ceiling Installation Video
Wall Installation Video
Advantages of using panels designed by FF Systems Inc.
